Features



  1.  Motorised locking device
  2. Durability tested to 400,000 cycles
  3. Multi voltage from 12 to 30VDC
  4. Sleep-Mode Current less than 15mA@12VDC
  5. Fully monitored including Reed Switch for door position
  6. Up to 680 kg Holding Strength
  7. 5 year warranty



Specifications

Function

Mortice Mount, power-to-lock/power-to-release field interchangeable, up to 35kg of Pre-Load capability

Voltage / Current

Multi Voltage 12-30VDC, Active Mode: Locking/Unlocking cycle current is 0.29A to 0.85A depending on the side load. More side load = more current., Sleep-Mode: After locking/unlocking the current drops down to ~0.015A (15mA)

Monitoring

Lock Status Sensor of the internal locking mechanism, Door Status Sensor Built-in Reed Switch, monitoring the door position

Environmental

Operational Temperature Range -20° to +60°C

Door Misalignment

Standard Strike Plate ±4mm Special Strike Plate up to ±12mm

Minimum Door Thickness

35mm
