Features



  1. Door and Lock Status Monitoring Sensor (DSS and LSS with “M” models)
  2. Built-in varistor (MOV) surge protection
  3. CE/C-Tick
  4. SCEC Approved for secure area (FEM5700M and DM)
  5. Anti-tamper plate (with “M” models)
  6. Long distance Light Panel (LP)



Specifications

Holding Strength

Up to 580kg (for single magnetic lock)

Voltage / Current

Dual Voltage 12/24VDC, 12VDC= 500mA (Double x2) 24VDC= 250mA (Double x2)

Approvals

4-hour fire rated to AS and BS Standards, SCEC approved for secure areas (FEM5700M and DM)

Dimensions

Single door series magnet: 268mm (L) x 73mm (W) x 40mm (D)

Double door series surface magnet: 535mm (L) x 73mm (W) x 40mm (D)

Single door series armature plate: 190mm (L) x 61mm (W) x 16mm (D)

Double door series armature plate: 190mm (L) x 61mm(W) x 16mm (D) x 2 pieces

Single door series DSS-armature plate: 252mm (L) x 61mm (W) x 16mm (D)

Double door series DSS-armature plate: 252mm (L) x 61mm (W) x 16mm (D) x 2 pieces
