Features



  1. Suitable for all types of single doors
  2. Can be used in conjunction with an 8827EO surface mounted vertical rod device and 1609 strike for double rebated door applications
  3. When 88EO is used in conjuctions with 8827EO and 1609 strike on double rebated doors, the minimum stile width is 117mm
  4. Field sizeable to accommodate a range of door openings
  5. Single point locking device, with a 19mm throw latch.



Specifications

Door Type

All door types

Door Thickness

Combination of fasteners are furnished for surface mounting or through bolting Surface mounted - 19mm minimum Through bolt - 44mm to 57mm

Door Size

Door width 600mm minimum, Stile width 111mm minimum with standard 299 strike 100mm minimum with optional 1606 strike

Hinge Style Case

152mm x 44mm x 24mm

Lock Style Case

233mm x 67mm x 24mm

Crossbar Length

1067mm - field sizeable
