Features



  1. Rim device has deadlocking latch with 19mm throw
  2. Vertical rod device has deadlocking latches with 16mm throw
  3. Available in 914mm and 1220mm lengths to suit a range of door openings
  4. Vertical rod device suitable for doors up to 2134mm (3050mm-high when fitted with extension rods)
  5. ‘F’ models are fire rated and have no dogging (hold open) feature
  6. Optional external trims available for key access



Specifications

Door Thickness

Combination of fasteners are furnished for surface mounting or through bolting, surface mounted - 19mm minimum, through bolt - 44mm to 57mm

Stile Width

121mm minimum with standard 299 strike, 100mm minimum with optional 1606 strike

Door Width

914mm length - 673mm minimum*, 1220mm length - 825mm minimum* (* based on standard strike and 13mm stop)

Handing

Reversible

Latch

19mm throw, deadlocking

Dogging

Hex key dogging
