Part No. | FEM4300(Single) FEM4300D(Double) | FEM4300M(Single) FEM4300DM(Double) |
Holding Strength | Up to 280kg (for single magnetic lock) | Up to 280kg (for single magnetic lock) |
Voltage/Current | Dual Voltage 12/24VDC 12VDC= 500mA (Double x2) | Dual Voltage 12/24VDC 12VDC= 500mA (Double x2) |
Approvals | Up to 2-hours fire rated in accordance with AS1905.1:2015 (contact Allegion for more details) | Up to 2-hours fire rated in accordance with AS1905.1:2015 (contact Allegion for more details) |
Monitoring | N/A | Red-Green Bi-colour LED Lock Status Sensor (LSS) Door Status Sensors (DSS) |
Size
| Single door series magnet: 238mm (L) x 48mm (W) x 25mm (D) Single door series armature plate: 185mm (L) x 38mm (W) x 12mm (D) | Double door series magnet: 476mm (L) x 48mm (W) x 25mm (D)
185mm (L) x 38mm (W) x 12mm (D) x 2 pieces |
