Brio’s 286 Dual Point Lock is suitable for Brio’s exterior folding system Weatherfold 4s with timber or aluminium panels (also suitable for single hinge panels, French doors etc.). The 180° operation of the low profile handle activates a 25mm throw to lock off doors securely top and bottom. Locking and non-locking options available, all with an integrated escutcheon for elegant, clean lines.
No fuss hinge fixing blocks and simple machining make this dual point lock quick and easy to install. The matching 288M magnetic lever handle operates with any 85mm centre lock and is also available in alloy satin nickel and powder coat black.
Specification – Timber
Min panel thickness: 38mm (Hardwood)
Max panel thickness: 70mm
Max panel height: 3.5m
Backset: 35 or 45mm
Throw length: 25mm
Security: 3 pin 20/10 Euro Cylinder
Key: Low profile and standard supplied
Tip type: SS 15x5mm bar
Hinge type: Non Mortice
Handle Material: Stainless Steel or Cast Alloy*
Handle Finishes: Satin & Polished Stainless or Satin Nickel
Specification – Aluminium
Min panel thickness: 35mm
Max panel thickness: 70mm
Max panel height: 3.5m
Backset: min 35mm
Throw length: 25mm
Security: 5 pin 30/10 Euro Cylinder
Key: Low profile and standard supplied
Tip type: SS Ø12mm or 512 equivalent tip
Handle Material: Stainless Steel or Cast Alloy*
Handle Finishes: Satin & Polished Stainless or Satin Nickel
